| Wide band I/P Frequency Range | 10.70 ~ 12.75 GHz |
| O/P Frequency Range | 300 ~ 2350 MHz |
| LO Frequency @ 25°C | 10.4 GHz ± 1 MHz |
| LO Temperature Drift (-30 ~ +60 °C) | 10.4 GHz ± 2 MHz |
| LO Phase Noise | -80dBc/Hz @ 10KHz |
| Noise Figure Max dB | 1dB Max. |
| Conversion Gain | 50dB ~ 60dB |
| Gain Variation | 5dB (max.) |
| Gain Flatness (27 MHz) | ±0.5dB/27MHz |
| Cross Polarization isolation | 22dB (min.) |
| Image Rejection (8.05-10.1 GHz) | 40dB (min.) |
| P1dB | 0dBm (min.) |
| O/P VSWR | 2.5:1 (max.) |
| O/P Spurious | -60dBm (max.) |
| DC Power 10-10V max. mA | 150mA Max. |
| Feed Horn Diameter | 55mm |
| Neck Diameter | 40mm |
